UT70A UNI-T
Modern Digital Multi-Purpose Multimeter UT70A AC / DC Frequency Temperature Diode Transistor
Warm prompt : UNI-T UT70 series only screend in Chinese display, unable to not transferred to English, suggest to choose UT71 series.
Features
1. We will ship the items within 3 business days after the payment is reached.
2. The items will be shipped via EMS (Express Mail Service). and they will be Marked as “gift” or “sample” for easy customs clearance
3. The shipment usually takes about 7-10 business days to reach at your designated address.
4. A telephone number is important when you leave your address
5. Each parcel has a tracking number for taking track of, you take track of it, please let us know if you still can’t receive the items within 15 days after you paid, then we will investigate.
Product parameters
| The basic functions | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 200mV / 2V / 20V / 200V / 1000V | (0.5% + 1) |
| AC Voltage | 200mV / 2V / 20V / 200V / 750V | (0.8% + 3) |
| DC Current | 20mA / 2mA / 200mA / 10A | (0.8% + 1) |
| AC Current | 20mA / 2mA / 200mA / 10A | (1% + 3) |
| Resistance | 200 W / 2kW / 20kW / 200kW / 2 MW / 20 MW / 2000 MW | (0.8% + 1) |
| Of capacity | 20nF / 200nF / 2mF / 100mF | (2.5% + 5) |
| Temperature (° c) | -40oC ~ 1000oC | (1% + 3) |
| Temperature of (di) | -40oF ~ 1832oF | (1% + 4) |
| Frequency | 2kHz-10MHz (Auto Going) | (0.1% + 3) |
| Inductance | 2mH / 20mH / 200mH / 20H | (2% + 10) |
| Logic | TTL (High> 2.0V, Low <0.8) | |
| Special functions | ||
| Spindle 10A Gamma | ||
| Diode | ||
| Continuity buzzer | ||
| Transistor | ||
| Peak Hold | ||
| Data in Possession | ||
| Display backlight | ||
| Full Display of Icons | ||
| Sleep mode | ||
| Low battery display | ||
| Max. Display | 1999 |
Basic parameters
| Power supply | 9V Battery (6F22) |
| LCD size | 62x53mm |
| Product Color | UT70A-Gray, Holster-Red |
| Net weight of the product | 620g (including holster) |
| Product format | 195x90x40mm |
| Standard accessories | Test Lead, Battery, English Manual, Contact Point Temperature Probe, Test Clip, Multi-Purpose Socket, Holster |
| Optional accessories * | Clip-On Test Lead Light (UT-TL), Built-in Test Lead Light (UT-L1), Built-in Test Lead Light Plus (UT-L2), Carrying Bag |
| Standard Packing | Gift box |
